OEM Standard Kubota V3307 Gasket Kit Complete Sealing Kubota Engine Parts

1 SET
MOQ
$55-$85
Price
OEM Standard Kubota V3307 Gasket Kit Complete Sealing Kubota Engine Parts
Features Gallery Product Description Chat Now
Features
Specifications
Brand: Kubota
Product Type: Kubota V3307 Excavator Overhaul Gasket Kit
Application: Kubota V3307 Powered Excavators, Tractors, Industrial Machinery
Quality Standard: OEM Standard (Matches Kubota Original Specifications)
Warranty: 6 Months Warranty
Worldwide Shipping: Yes (Fast Delivery To Global Destinations)
Material Grade: High-Grade Heat-Resistant & Oil-Resistant Industrial Sealing Material
Certification: ISO Certified
Highlight:

OEM Gasket Kit

,

V3307 Gasket Kit

,

V3307 gasket set
Basic Infomation
Place of Origin: CHINA
Brand Name: For Kubota
Certification: ISO 9001/IATF 16949
Model Number: V3307
Payment & Shipping Terms
Packaging Details: Inner: Airtight PE bag + desiccant + EPE foam protection, with certificate & guide Outer: 5-ply corrugated carton (30×30×30cm, 3kg/set), neutral packing, custom marks available
Delivery Time: 3-8 days
Payment Terms: T/T, Western Union, D/A
Supply Ability: 10000PCS/ WEEK
Product Description


OEM Standard Kubota V3307 Gasket Kit Complete Sealing Durable Kubota Engine Parts


SKU: KV3307-GK01

Premium direct-fit sealing solution for Kubota V3307 diesel engines—engineered to OEM standards for excavators, tractors, skid steer loaders and all V3307-powered construction/agricultural machinery. This complete gasket overhaul kit solves all oil, water and air leakage issues, with genuine-matching part numbers for one-stop replacement and long-lasting performance. All components are ISO/ROHS certified, making it the reliable choice for professional engine maintenance and full overhaul projects.


Core OEM Part Numbers


Top Gasket Set: K1G777-99353 | Bottom Gasket Set: K1G777-99364

Cylinder Head Gasket: K1G777-03310 / K1G777-03600 / K1G777-03610

Valve Cover Gasket: K1G772-14520 | Crankshaft Front Oil Seal: K1C020-04140

Crankshaft Rear Oil Seal: K1G772-04460 | Fuel Injector Seal Ring Sets: OEM matching specs


Product Specification Table


Specification CategoryDetails
Product NameKubota V3307 Engine Gasket Overhaul Full Set
SKUKV3307-GK01
Core OEM Part NumbersTop Gasket Set: K1G777-99353
Bottom Gasket Set: K1G777-99364
Cylinder Head Gasket: K1G777-03310/K1G777-03600/K1G777-03610
Valve Cover Gasket: K1G772-14520
Crankshaft Front Oil Seal: K1C020-04140
Crankshaft Rear Oil Seal: K1G772-04460
Applicable EngineKubota V3307-DI / V3307-DIT / V3307-CR 4-Cylinder Diesel Engine
Main MaterialCylinder Head Gasket: Metal composite + high-temperature rubber
Oil Seals: FKM/NBR rubber + metal skeleton
General Gaskets: EPDM rubber / asbestos-free fiber + metal sheet
Key PerformanceTemperature Resistance ≤180℃
Pressure Resistance ≤1.5MPa
0 Leakage (Oil/Water/Air)
Diesel engine oil corrosion & aging resistance
CertificationsISO 9001, ROHS (2011/65/EU), OEM Exact Fit Certificate
Kit Content28+ complete pieces - cylinder head gasket, valve cover gasket, crankshaft front/rear oil seals, camshaft oil seals, water pump gasket, oil pan gasket, intake/exhaust manifold gaskets, fuel injector seal rings, all small gaskets/seal rings
Compatible MachineryKubota Excavator (KX080-3, KX080-4)
Bobcat Skid Steer Loader (S630, S650, T630, T650)
Kubota Tractor (M6040, M6060, M7060)
All V3307-powered construction/agricultural machinery
PackagingInner: Airtight PE bag + desiccant + EPE foam partition
Outer: 5-ply reinforced corrugated carton (30×30×30cm)
Gross Weight: 3.0kg/set
Warranty12 months / 1000 working hours (whichever comes first)
MOQ1 set (bulk discount for 50+/100+ sets)


Key Features


✅ 100% Exact OEM Fit - Precision-machined dimensions, no modification needed for direct installation on Kubota V3307 engines

✅ Durable High-Grade Materials - FKM/NBR rubber and metal composite components for extreme high temp, oil and pressure resistance

✅ Complete One-Stop Kit - All sealing parts included with marked OEM part numbers, easy to identify and install

✅ Global Compliance - ISO/ROHS certified, meets EU/NA international shipping and quality standards

✅ Zero Leakage Performance - Special textured sealing surfaces compensate for engine body slight deformation, ensuring perfect sealing


Compatible Models


Kubota Engines: V3307-DI, V3307-DIT, V3307-CR 4-Cylinder Diesel Engines

Kubota Machinery: KX080-3/KX080-4 Excavators | M6040/M6060/M7060 Tractors

Bobcat Machinery: S630/S650/T630/T650 Skid Steer Loaders

All other construction, agricultural and industrial machinery powered by Kubota V3307 engines


Quality Assurance & After-Sales


We stand behind our Kubota engine parts with a 12-month/1000 working hours warranty (whichever comes first). If any sealing failure occurs due to product material or processing defects, we provide free replacement or full refund. Our professional technical team offers 7×24 online support for installation guidance and part matching—ensuring a smooth maintenance process for your machinery.

Kubota Engine Parts You Can Trust - This V3307 gasket overhaul kit is the perfect OEM replacement for your Kubota machinery, delivering reliable sealing performance and extending engine service life!
